| Waveguide Type | WR28 | WR42 | WR51 | WR62 |
| Frequency (GHz) | 26.3-40.0 | 17.6-26.7 | 14.5-22.0 | 11.9-18.0 |
| VSWR | 1.05 | 1.05 | 1.05 | 1.05 |
| Insertion Loss (dB) max | 0.1 | 0.1 | 0.1 | 0.1 |
| Material | Al/Cu | Al/Cu | Al/Cu | Al/Cu |
| Waveguide Type | WR75 | WR90 | WR112 | WR137 |
| Frequency (GHz) | 9.84-15.0 | 8.20-12.50 | 6.57-9.99 | 5.38-8.17 |
| VSWR | 1.05 | 1.05 | 1.05 | 1.05 |
| Insertion Loss (dB) max | 0.1 | 0.1 | 0.1 | 0.1 |
| Material | Al/Cu | Al/Cu | Al/Cu | Al/Cu |
| Waveguide Type | WR187 | WR229 | WR284 | WR650 |
| Frequency (GHz) | 3.94-5.99 | 3.22-4.90 | 2.60-3.95 | 1.12-1.7 |
| VSWR | 1.05 | 1.05 | 1.05 | 1.05 |
| Insertion Loss (dB) max | 0.1 | 0.1 | 0.1 | 0.1 |
| Material | Al/Cu | Al/Cu | Al/Cu | Al |
